Explore EX40 specifications
Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.
Platform
Platform
Fuel Type
Electric
Driveline
RWD
Transmission
Automatic
Number of seats
5
Weight (Running Order Mass)
2 040 kg
Weight (Max Laden Mass)
2470 kg
Trailer max weight
1 500 kg
Roof load max weight
75 kg
Performance
Electric Range (Combined)
480 km
Electric energy consumption
18.7 kWh/100km
Power
175 kW / 238 hp
Max torque
420 Nm
0-100 km/h
7.3 s
Top speed
180 km/h
Environmental Classification
Euro6e
Charging
Battery energy (nominal)
70 kWh
Battery Charging Duration
7 h
Battery Charging Duration
26 m
Fuel Type
Electric
Driveline
AWD
Transmission
Automatic
Number of seats
5
Weight (Running Order Mass)
2 170 kg
Weight (Max Laden Mass)
2650 kg
Trailer max weight
1 800 kg
Roof load max weight
75 kg
Electric Range (Combined)
540 km
Electric energy consumption
19.4 kWh/100km
Power
300 kW / 408 hp
Max torque
670 Nm
0-100 km/h
4.8 s
Top speed
180 km/h
Environmental Classification
Euro6d
Battery energy (nominal)
82 kWh
Battery Charging Duration
8 h
Battery Charging Duration
28 m
Car dimensions
Exterior
Vehicle height at kerb weight with one person
1 651 mm
Width (mirrors incl)
2 034 mm
Front track width
1 601 mm
Width
1 873 mm
Width (mirrors folded)
1 938 mm
Rear track width
1 608 mm
Vehicle length
4 440 mm
Wheel base
2 702 mm
Turning circle
11 m
Interior
Max head room front
1 030 mm
Shoulder room rear
1 429 mm
Hip room front
1 390 mm
Head room rear
994 mm
Leg room front
1 040 mm
Hip room rear
1 388 mm
Shoulder room front
1 440 mm
Leg room rear
917 mm
Storage
Cargo floor width between wheel housing
1 004 mm
Second seatback to tailgate - top of second seatback
676 mm
First seatback to tailgate - top of first seatback
1 527 mm
Cargo capacity (max) - second row up
536 l
Cargo capacity (max) - rows folded
1 400 l
Cargo capacity (front)
31 l
